The Saramonic TX-XLR9 Plug-on XLR Transmitter allows you to connect any XLR microphone to the UWMIC9 Wireless System. It features a wide switching RF bandwidth, an easy-to-read LCD display, +48V phantom power, and mute function. The TX-XLR9 provides stable, interference-free audio in portable, compact and low-cost package. It is suitable for portable wireless operation and can be used in a wide range of applications such as DSLR video, broadcast TV, ENG and more.

– Wireless plug-on transmitter compatible with RX9 receiver
– 514 MHz – 596 MHz
– 96 selectable channels
– XLR audio input jack
– +48V phantom power
– Easy-to-read LCD displays
– Works with various types of XLR microphones

Specifikime

Channels 96 selectable channels in 2 groups (A and B)
Wireless Frequency Range 514 MHz – 596 MHz
Oscillator Type PLL synthesizer
Input Locking XLR Connector
Phantom Power Selectable +48V Phantom Power (On/Off)
Reference audio input level –60 dBV (MIC input, 0 dB attenuation)
Antenna 1/4 λ wire antenna
Signal to Noise Ratio 70 dB or more
Voice Delay 12 ms
Reference Deviation +/- 5 kHz (-60 dBV, 1 kHz input)
Frequency Response 40 Hz to 18 kHz (+/- 3dB)
Distortion 0.5% or less
Spur Suppression -60 dB
Batteries 2 LR6/AA size batteries
Dimensions 4.15 x 1.69 x 1.37” (105.5 x 43 x 34.7mm)
Weight 4.87 oz (138g) (without batteries)
