Specifications
– Nautilus™ tube loaded aluminum dome tweeter
– Glassfiber cone bass/midrange
– Auxiliary Bass Radiator (ABR)
– Description: 2-way system with Auxiliary Bass Radiator (ABR)
– Drive units: 1x ø25mm (1in) aluminum dome high-frequency, 1x ø130mm (5in) glassfiber cone bass/midrange
– Frequency range: -6dB at 46Hz and 50kHz (wall mounted)
– Frequency response: 51Hz – 22kHz on reference axis (wall mounted)
– Sensitivity: 86dB (2.83V, 1m)
– Total harmonic distortion: <1% 200Hz – 20kHz (86dB, 1m)
– Nominal Impedance: 8Ω (5.2 Ω min)
– Recommended amplifier power: 20W – 100W into 8Ω on unclipped program
Dimensions (includes wall bracket)
– Height: 310mm (12 1/4in)
– Width: 180mm (7in)
– Depth: 210mm (8 1/4in)
– Net weight: 4kg (8.8lb)
– Finishes: Matte white or Matte black
